Tutorial: GNU gcov Coverage with the NXP i.MX RT1064

This tutorial shows how to use and collect coverage data using the GNU gcov tool. As board and hardaware I’m using the NXP i.MX RT1064 EVK:

MIMXRT1064-EVK running ThreadX
MIMXRT1064-EVK

While this tutorial uses this specific board, things are pretty generic and should be applicable for any other board or MCU.

Continue reading

Placing Code in Sections with managed GNU Linker Scripts

Managed linker scripts are great on one side: the simplify the otherwise complex GNU linker script handling. On the other side it requires knowledge how to tweak them in case ‘non-standard’ behavior is needed.

Continue reading

Tutorial: GNU Coverage with MCUXpresso IDE

If you are developing Linux or desktop applications with GNU tools, you  very likely are familiar with gcov: the GNU coverage tool. It collects data what parts of the code gets executed and represents that in different formats, great to check what is really used in the application code or what has been covered during multiple test runs.

Coverage Information with gcov

Coverage Information with gcov

line never executed

line never executed

GNU coverage is possible for resource constraint embedded systems too: it still needs some extra RAM and code space, but very well spent for gathering metrics and improves the firmware quality. As I wrote in “MCUXpresso IDE V11.3.0 for 2021” things are now easier to use, so here is a short tutorial how to use it.

Continue reading

Visualizing Data with Eclipse, gdb and gnuplot

The gnuplot is a versatile and powerful tool to plot and visualize all kind of data. I wish there would be a plugin for it in Eclipse. But as this is not (yet?) the case, here is how I’m using it with gdb and Eclipse, using the MCUXpresso IDE as example.

Gnuplot with Eclipse

Gnuplot with Eclipse

Continue reading

Tutorial: MCUXpresso SDK with Linux, Part 3: RAM and XiP Code on i.MX RT1064

In my previous articles I have used the command line on Linux to build and debug NXP MCUXpresso SDK applications. In this article I’m running code on NXP i.MX RT1064 in RAM or FLASH.

i.MXRT1064 board with LPC845-BRK as debug probe

i.MXRT1064 board with LPC845-BRK as debug probe

Continue reading

Different Ways of Software Configuration

Most of the time software needs some way to configure things: depending on the settings, the software will do different things. For example the software running on the microcontroller on top of the Raspberry might have the OLED LCD available or not:

Raspberry Pi and tinK22 with OLED LCD

Raspberry Pi and tinyK22 (NXP Kinetis K22FN512) with OLED LCD

How can I deal with this in my application code? Continue reading

GNU Link Time Optimization finds non-matching Declarations

By default, the GNU compiler (gcc) optimizes each compilation unit (source file) separately. This is effective, but misses the opportunity to optimize across compilation units. Here is where the Link Time Optimization (LTO,  option -flto) can help out: with a global view it can optimize one step further.

The other positive side effect is that the linker can flag possible issues like the one below which are not visible to the compiler alone:

type of '__SP_INIT' does not match original declaration [enabled by default]

Warning by LTO

Warning by LTO

Continue reading

Listing Code and Data Size with GNU nm in Eclipse

The map file produced by the GNU linker includes lots of information, however it is very cryptic to read. In “Listing Code and Data Size for each Source File with GNU and Eclipse” I showed how the GNU size utility can be used to report the code and data size for each object file. The Eclipse based MCUXpresso IDE comes with another nice view which shows detailed information about code and data allocation:

Symbol Viewer in MCUXpresso IDE

Symbol Viewer in MCUXpresso IDE

Continue reading

Solving Problem with GNU Linker and “referenced in section, defined in discarded section ” Error Message

I have been running recently into an interesting case where the GNU ARM Linker failed to link an application with strange error messages:

referenced in section, defined in discarded section

referenced in section, defined in discarded section

Continue reading

Using the GNU Linker Script to know the FLASH and RAM Areas in the Application

Sometimes it is handy to know in the running application the start address, end address and the size of a linked section, e.g. to know the boundaries of RAM or FLASH areas. This means that from the application code I can get access to knowledge of the GNU linker:

Information about Linker Sections

Information about Linker Sections

Continue reading
