Girls for Science!

Working in an engineering domain of electrical engineering and computer science, female engineers are clearly the minority, at least in my country. For example the ETH Zurich has less than 30% female students. The US National Science Foundation had published articles on that subject: Interestingly, 70% of young girls are interested in math and science, but they lose that interest afterwards.

Verizon Commercial 2014 (Source: Youtube)

Verizon Commercial 2014 (Source: Youtube)

Continue reading

Advertisements

The Turbo Encabulator

At the university the mid-term presentations are due. Which reminds me about the importance to use the right terms and keywords not only for scientific presentations and abstracts, but as well to use and know the correct terms in any presentation or documentation. A have been pointed to an interesting concept: The Turbo Encabulator, described in this data sheet:

Turboencabulator

Turboencabulator

Continue reading

IoT: FreeRTOS Down to the Micro Amps

University research projects can be a lot fun, and are very challenging the same time. The good thing is that there is always someting new to learn :-).

This week-end I was working on my Internet of Things (IoT) project, based on a Freescale KL15Z and a nRF24L01+ transceiver. In essence it is a wireless data logger. For this, I only can afford a few micro amps consumed by the whole board over an extended period of time. I mean 21 micro amps for running a whole board with sensor, EEPROM, wireless transceiver, operating system and an ARM Cortex-M0+ ready to crunch numbers at 20 MHz 🙂

21 micro amps for wireless sensor node

21 micro amps for wireless sensor node (when not sending)

Continue reading

Historic Win in Silverstone: Congratulations to the AMZ Formula Student Team!

It has been a very successful racing week in Silverstone/UK: The AMZ Formula Student team, formed by students of the ETH Zurich and the Lucerne University of Applied Sciences and Arts, won the first overall place at this prestigious engineering event!

Julier in Silverstone (Picture: Benjamin Hildebrandt)

Julier in Silverstone (Picture: Benjamin Hildebrandt)

Continue reading

Adding Quadrature Encoder to the Zumo Chassis

The Pololu Zumo chassis is nearly perfect for my needs: it is small and compact, and neatly works with the FRDM-KL25Z board. I’m able to use it for line following or maze solving. But it lacks a position (quadrature) encoder on the wheels which is either very useful or even required for the lecture assignments for my next class. The Pololu Zumo chassis mainly has been designed for Robot-Sumo competitions, where such quadrature sensors are not really needed. Pololu offers optical quadrature sensors for their 42×19 mm wheel which I used in this project. So why not adding these sensors to the Zumo chassis?

FRDM-Robot with Quadrature Sensors Mounted

FRDM-Robot with Quadrature Sensors Mounted

Continue reading

Julier 4WD Test Drive in Alpnach

While weather is bad and Switzerland suffers from record high rain water levels, the Formula Student “julier” team was testing their race car this week-end after the rollout. This time to test the 4WD with more torque. Plus water-resistance ;-). So here are impressions, pictures and a video from this week-end:

Julier Formula Student Race Car

Julier Formula Student Race Car

Continue reading

Rollout of ‘julier’ Formula Student Race Car

Last Thursday the new Formula Student race car named ‘julier’ had its rollout to the public at Sauber Motorsports in Hinwil, Switzerland. Again a fully electrical racing car, but this time with 4-wheel drive, improved aero-pack and electronics, and able to get from 0 to 100 km/h in 2.6 seconds!

Julier racing (Source Benjamin Hildebrandt)

Julier racing (Source Benjamin Hildebrandt)

Continue reading
